| Type | Boundary Dimensions(mm) | Basic Load Rating (kN) | Weight | |||
| d | D | T | Cr. | Cor. | (Kg) | |
| 02474/02420 | 28.575 | 68.263 | 22.225 | 51 | 61.1 | 0.402 |
| 02475/02420 | 31.75 | 68.263 | 22.225 | 51 | 61.1 | 0.374 |
| 02872/02820 | 28.575 | 73.025 | 22.225 | 55 | 65.7 | 0.477 |
| 07093/07196 | 23.812 | 50.1 | 13.495 | 26 | 27.9 | 0.12 |
| 07097/07196 | 25 | 50.1 | 13.495 | 26.7 | 28.8 | 0.12 |
| 07100/07204 | 25.4 | 51.99 | 15.011 | 26.7 | 28.8 | 0.12 |
| 07100S/07196 | 25.4 | 50.005 | 13.495 | 26.7 | 28.8 | 0.12 |
| 09067/09195 | 19.05 | 49.225 | 18.034 | 37.7 | 37.7 | 0.179 |
| 09067/09196 | 19.05 | 49.225 | 21.209 | 39.7 | 37.7 | 0.19 |
| 09074/09194 | 19.05 | 49.225 | 23.02 | 39.7 | 40.5 | 0.2 |
| 09074/09195 | 19.05 | 49.225 | 19.845 | 38.5 | 39 | 0.18 |
| 09074/09196 | 19.05 | 49.225 | 23.02 | 37.7 | 37.7 | 0.2 |
| 11162/11300 | 41.275 | 76.2 | 18.009 | 42.5 | 51.5 | 0.34 |
| 11590/11520 | 15.875 | 42.863 | 14.288 | 17.8 | 17.7 | 0.098 |
| 12580/12520 | 20.638 | 49.23 | 19.845 | 27.5 | 39 | 0.18 |
| 13686/13621 | 38.1 | 69.012 | 26.195 | 49.2 | 62 | 0.352 |
| 14125A/14276 | 31.75 | 69.012 | 19.845 | 48.5 | 58 | 0.35 |
| 14131/14276 | 33.338 | 69.012 | 19.845 | 47 | 56 | 0.34 |
| 15101/15245 | 25.4 | 61.999 | 19.05 | 44.6 | 50.7 | 0.296 |
| 15101/15245X | 25.4 | 63.5 | 19.05 | 44.6 | 50.7 | 0.33 |
| 15112/15245 | 28.575 | 61.999 | 19.05 | 44.6 | 50.7 | 0.271 |
| 15116/15245 | 30.112 | 62 | 19.05 | 44.6 | 50.7 | 0.26 |
| 15123/15245 | 31.75 | 61.999 | 18.161 | 44.6 | 50.7 | 0.23 |
| 15126/15245 | 31.75 | 61.999 | 19.05 | 44.6 | 50.7 | 0.25 |
| 16150/16282 | 38.1 | 71.996 | 19 | 49.7 | 61.3 | 0.33 |
| 17887/17831 | 45.23 | 79.985 | 19.842 | 62 | 78.5 | 0.401 |
| 18590/18520 | 41.275 | 73.025 | 16.667 | 45.9 | 55.8 | 0.28 |
| 24780/24720 | 41.275 | 76.2 | 22.225 | 66.3 | 83.3 | 0.42 |
| 25572/25520 | 38.1 | 82.931 | 23.813 | 77.2 | 100 | 0.64 |
| 25577/25520 | 42.975 | 82.931 | 23.813 | 77.2 | 100 | 0.58 |
| 25580/25520 | 44.45 | 82.931 | 23.813 | 76.5 | 99 | 0.55 |
| 25590/25520 | 45.618 | 82.931 | 23.813 | 76 | 98 | 0.54 |
| 25590/25523 | 45.618 | 82.931 | 26.988 | 76 | 98 | 0.58 |
| 25877/25821 | 34.925 | 73.025 | 23.812 | 72 | 87.3 | 0.47 |
| 28680/28622 | 55.563 | 97.63 | 24.608 | — | — | 0.766 |
| 29585/29522 | 63.5 | 107.95 | 25.4 | — | — | 0.901 |
| 29590/29522 | 66.675 | 107.95 | 25.4 | — | — | 0.854 |
| 59200/59412 | 50.8 | 104.8 | 36.5 | — | — | 1.42 |
| 1280/1220 | 22.225 | 57.15 | 22.225 | 52.6 | 55.7 | 0.294 |
| 1755/1729 | 22.225 | 56.896 | 19.368 | 40 | 43.1 | 0.25 |
| 1780/1729 | 25.4 | 56.896 | 19.368 | 40 | 43.1 | 0.2 |
| 1988/1922 | 28.575 | 57.15 | 19.845 | 48.8 | 57.1 | 0.227 |
| 2580/2520 | 31.75 | 66.421 | 25.4 | 71.4 | 85.1 | 0.4 |
| 2580/2523 | 31.75 | 69.85 | 23.812 | 69 | 81.5 | 0.45 |
| 2788/2720 | 38.1 | 76.2 | 23.813 | 74.1 | 92.2 | 0.49 |
| 3490/3420 | 38.1 | 79.375 | 29.37 | 87.4 | 105 | 0.645 |
| 3579/3525 | 42.863 | 87.313 | 30.162 | 94 | 117 | 0.79 |
| 3782S/3720S | 44.45 | 93.264 | 30.163 | — | — | 0.96 |
| 320/28 | 28 | 52 | 16 | 33.5 | 40 | 0.143 |
| 332/28 | 28 | 58 | 24 | 57.6 | 69.5 | 0.158 |
| 320/32 | 32 | 58 | 17 | 39.2 | 50.6 | 0.188 |
| 332/32 | 32 | 65 | 26 | 71.8 | 86.9 | — |
| 368/362 | 50.8 | 90 | 20 | — | — | 0.507 |
| 368/362A | 50.8 | 88.9 | 20.638 | 74.3 | 87.3 | 0.51 |
| 368A/362A | 50.8 | 88.9 | 20.638 | 74.3 | 87.3 | 0.5 |
| 386A/382A | 47.625 | 96.838 | 21 | 80 | 101 | 0.73 |
| 418/414 | 38.1 | 88.5 | 26.988 | 98.2 | 112 | 0.848 |
| 527/522 | 44.45 | 101.6 | 34.925 | 131 | 159 | 1.36 |
| 535/532A | 44.45 | 111.13 | 38.1 | 138 | 172 | 1.83 |
| 575S/572S | 76.2 | 139.99 | 36.513 | — | — | 2.391 |
| 580S/572S | 82.55 | 139.99 | 36.513 | — | — | 2.167 |
| 582S/572S | 82.6 | 140 | 36.5 | — | — | 2.145 |
| 594A/592A | 95.25 | 152.4 | 39.688 | — | — | 2.49 |
| 594S/592AS | 95.25 | 152.4 | 39.688 | — | — | 2.5 |
| 594AS/592AS | 95.25 | 152.4 | 39.688 | — | — | 2.49 |
| 598S/592AS | 92.075 | 152.4 | 39.688 | — | — | 2.62 |
| 598AS/592AS | 92.075 | 152.4 | 39.688 | — | — | 2.6 |
| 663S/653S | 82.55 | 146.05 | 41.275 | — | — | 2.78 |
| 778/772 | 92.08 | 180.98 | 47.6 | — | — | 5.65 |
| 795/792 | 120.65 | 206.38 | 47.625 | — | — | 6.41 |
| 898/892 | 139.7 | 228.6 | 57.15 | — | — | 8.88 |
