parameter

Overall dimension: 2600*1800*2100mm

Fan motor: 1.5 kw

Air compressor: 7.5kw

Electric heating: 0.5 kw

Total power: 23kw

Snow nozzles: 106

Nucleon: 20

Nozzle turns: 3 rows

Rotation Angle: 360 degrees

Angle of elevation: 50 degrees

Snow making temperature: -35℃ ~ 0℃

Snow output: 50 ~ 80m cubed /h

Head: 40 ~ 120m

Supply voltage: 380 volts

Quick power connection: 63A

Structure: 3 tires and rotatable bracket



Use and maintenance



Check whether the power connection is illusory before starting. Whether the voltage is stable. If the generator is powered, the continuous power supply shall not be less than 380 volts. Whether the valve is frozen and blocked. If blocked, electric heating can be turned on for preheating. Whether the connection between nozzle, nucleon and nozzle is sealed. If sealing ring aging or leakage timely replacement. Make sure the fan and air compressor are running straight. The oil level of the air compressor is maintained at the red line. If there is ice when making snow, remove it in time to avoid spatter and injury. Check the pressure gauge and pressure relief valve performance before making snow every time. Belt tightening; Drain the remaining water in the pipeline after use. Clean nozzles and filters properly according to local water quality. Bearings, bolts, telescopic rods and turntables are oiled regularly to maintain the lubrication of each part. Change the oil and air filter element every snow season.
