EN 14700 T Fe8
• Tubular wire for submerged arc hardfacing
• Martensitic weld metal with good abrasion and impact resistance
• Self-tempering deposit for hardfacing
• Especially applicable in 2-3 layers for wear resistance
Hardface L-S is used when good resistance to abrasion and impact in dry or wet environments is required.
Examples
Bucket teeth, lips and undersides, cutting edges, steel mill rolls, cable drums, sand dredge equipment, dragline buckets, conveyor chutes, grizzly bars.
| 0.50 | 1.50 | 2.50 | 8.50 | Rest |
Structure: medium alloy martensitic
| DC (+) | WAF 325 |
| Classification | EN 760: S A FB 1 65 DC H5 | |
| Redrying | 2 hours at 250 - 350°C | |
| Packaging | bags (25 kg) | |
| 1.6 | 150 - 300 | 250 | 26 - 32 | 30 | 15 - 30 | 25 |
| 2.0 | 200 - 350 | 280 | 26 - 32 | 30 | 20 - 50 | 25 |
| 2.4 | 200 - 450 | 350 | 26 - 32 | 30 | 25 - 50 | 30 |
| 2.8 | 250 - 550 | 400 | 28 - 32 |
30 |
25 - 50 | 30 |
| 3.2 | 300 - 650 | 500 | 28 - 32 | 30 | 25 - 50 | 30 |
Recovery: 95 %
Flat
1.6, 2.0, 2.4, 2.8, 3.2
Other diameters: please consult us
| Standard packaging [EN ISO 544] | Spool : BS 300 | Coil : B 450 | Drum |
| Weight | 15 kg | 25 kg | Up to 330 kg |
