EN 14700 T Fe8
• Tubular wire for submerged arc hardfacing
• 13% chromium martensitic stainless steel deposit
• Attractive combination of corrosion, oxidation, scaling and wear resistance
Chromecore 420M-S is used for hardfacing and reclaiming components subject to moderate corrosion and metal-metal wear. The deposited alloy also has excellent gouging and abrasion resistant properties.
Examples
Extensively used as a cladding alloy on many types of steel industry rolling mill rolls such as table rolls, pinch rolls, scale breaker rolls, coiler rolls, leveller rolls and runout table rolls. Other applications include dragline rope sheaves, dragline rope drums, hydraulic plungers, certain types of valve seats, pulp rotors.
| DC (+) | WAF 325 |
| Classification | EN 760: S A FB 1 65 DC H5 | |
| Redrying | 2 hours at 250°C ± 50°C | |
| Packaging | bags (25 kg) | |
| 2.4 | 200 - 450 | 350 | 26 - 32 | 30 | 25 - 50 | 30 |
| 2.8 | 250 - 550 | 400 | 28 - 32 |
30 |
25 - 50 | 30 |
| 3.2 | 300 - 650 | 500 | 28 - 32 | 30 | 25 - 50 | 30 |
Recovery: > 95 %
Flat
2.4, 2.8, 3.2
Other diameters: please consult us
| Standard packaging [EN ISO 544] | Spool : BS 300 | Coil : B 450 | Drum |
| Weight | 15 kg | 25 kg | Up to 330 kg |
