CHROMECORE 414MM-S

CLASSIFICATION

EN 14700 T Fe7

DESCRIPTION

• Tubular wire for submerged arc cladding steel mill rolls
• The alloy has high hardness and excellent wear and galling resistance
• Ferritic-martensitic stainless steel weld deposit with excellent resistance to thermal fatigue

APPLICATIONS

Extensively used as a cladding alloy for rebuilding various steel mill rolls subject to repetitive thermal stresses, corrosion and metal-to-metal wear.
Typical applications include cladding of continuous caster rolls and certain rolls used in hot rolling applications.
Preheat prior to welding and slow cooling after welding is often essential with this alloy. In some instances, stress relieving of the components is advisable.

TYPICAL ALL-WELD METAL ANALYSIS Structure: martensite + ferrite TYPICAL ALL-WELD METAL MECHANICAL PROPERTIES Hardness – 3 layer deposit as welded: 42 – 48 HRc CONDITIONS OF USE Current typeShielding

DC (+)	WAF 325 or WAF 385

FLUX DESCRIPTION WAF 325 WAF 385

Classification	EN 760: S A AB 1 65 DC H5		EN 760: S A AB 2 65 DC H5
Redrying	2 hours at 250°C ± 50°C
Packaging	bags (25 kg)

OPERATING CONDITIONS DiameterAmperage [A]Voltage [V]Stick-out [mm] [mm]RangeOptimumRangeOptimumRangeOptimum

1.6	150 - 300	250	26 - 32	30	15 - 30	25
2.0	200 - 350	280	26 - 32	30	20 - 50	25
2.4	200 - 450	350	26 - 32	30	25 - 50	30
2.8	250 - 550	400	28 - 32	30	25 - 50	30
3.2	300 - 650	450	28 - 32	30	25 - 50	30

Recovery: >95%

WELDING POSITIONS

Flat

STANDARD DIAMETERS (mm)

1.6, 2.0, 2.4, 2.8, 3.2
Other diameters: please consult us

PACKAGING Diameter≤ 2.4 mm≥ 2.4 mm

Standard packaging [EN ISO 544]	Spool : BS 300	Coil : B 450	Drum
Weight	15 kg	25 kg	Up to 330 kg

Other packaging: please consult us
