| 型號 | STROKES | 精度指標 | OVERALL SIZE | WORK ENVELOPE | 系統凈重 | 被測工件最大重量 | |||||||||
| 行程范圍 | ISO10360-2:2001/GB/T16857.2-2006 | 主機外廓尺寸 | 允許工件尺寸 | ||||||||||||
| X | Y | Z | S | H | Lx | Ly | Lz | Wx | Wy | Wz | |||||
| mm | mm | mm | MPE(μm) | MPEP(μm) | MPEE(μm) | MPEP(μm) | mm | mm | mm | mm | mm | mm | Kg | Kg | |
| NCT454 | 400 | 500 | 400 | 2.1+3.3L/1000 | 2.1 | 1.3+3L/1000 | 1.3 | 1250 | 1450 | 2300 | 600 | 700 | 500 | 1200 | 400 |
| NCT564 | 500 | 600 | 400 | 2.1+3.3L/1000 | 2.2 | 1.3+3L/1000 | 1.3 | 1350 | 1550 | 2300 | 700 | 800 | 500 | 1400 | 500 |
| NCT685 | 600 | 800 | 500 | 2.4+3.3L/1000 | 2.4 | 1.5+3L/1000 | 1.5 | 1450 | 1850 | 2500 | 800 | 1000 | 600 | 1600 | 700 |
| NCT6105 | 600 | 1000 | 500 | 2.4+3.3L/1000 | 2.4 | 1.5+3L/1000 | 1.5 | 1450 | 2050 | 2500 | 800 | 1200 | 600 | 1750 | 1000 |
| NCT787 | 700 | 800 | 700 | 2.4+3.3L/1000 | 2.4 | 1.5+3L/1000 | 1.5 | 1450 | 1850 | 3000 | 900 | 1000 | 800 | 2000 | 1000 |
| NCT7107 | 700 | 1000 | 700 | 2.5+3.3L/1000 | 2.5 | 1.7+3L/1000 | 1.7 | 1450 | 2050 | 3000 | 900 | 1200 | 800 | 2200 | 1000 |
| NCT8107 | 800 | 1000 | 700 | 2.5+3.3L/1000 | 2.5 | 1.7+3L/1000 | 1.7 | 1550 | 2050 | 3000 | 1000 | 1200 | 800 | 2400 | 1000 |
| NCT8127 | 800 | 1200 | 700 | 2.5+3.3L/1000 | 2.5 | 1.7+3L/1000 | 1.7 | 1550 | 2250 | 3000 | 1000 | 1400 | 800 | 2600 | 1500 |
| NCT8157 | 800 | 1500 | 700 | 2.9+3.3L/1000 | 2.9 | 2.2+3L/1000 | 2.2 | 1550 | 2550 | 3000 | 1000 | 1700 | 800 | 2800 | 1500 |
| NCT10128 | 1000 | 1200 | 800 | 2.9+3.3L/1000 | 2.9 | 2.2+3L/1000 | 2.2 | 1750 | 2500 | 3200 | 1200 | 1400 | 900 | 3000 | 1500 |
| NCT10158 | 1000 | 1500 | 800 | 2.9+3.3L/1000 | 2.9 | 2.2+3L/1000 | 2.2 | 1750 | 2800 | 3200 | 1200 | 1700 | 900 | 3300 | 1800 |
| NCT10208 | 1000 | 2000 | 800 | 2.9+3.3L/1000 | 2.9 | 2.2+3L/1000 | 2.2 | 1750 | 3200 | 3200 | 1200 | 2200 | 900 | 4500 | 1800 |
| NCT121510 | 1200 | 1500 | 1000 | 3.6+3.3L/1000 | 3.6 | 2.6+3L/1000 | 2.6 | 1950 | 2800 | 3650 | 1400 | 1700 | 1100 | 4000 | 1800 |
| NCT12Y10 | 1200 | Y | 1000 | 3.6+3.3L/1000 | 3.6 | 2.6+3L/1000 | 2.6 | 1950 | 3650 | 1400 | 1100 | 2000 | |||
電源電壓(Power Voltage):220V
空氣壓力(Air Pressure):0.4-0.5Mpa
過濾精度(Filter Accuracy):0.3μm
空氣流量(Air Supply):0.12m3/min
溫度范圍(Temperature Range):18-22℃
溫度變化(Hourly Temperature Cycle):1℃/h
溫度梯度(Thermal Gradient):1℃/m
濕度范圍(Relative Humidity):55%-65%
