PRODUCT NAME |
STANDARD |
Specification |
||
|
AWS |
JIS |
KS |
||
| S-4301.I |
E6019 |
D4301 |
E4301 |
Ship building, Highest reliability required parts |
| S-4303.V |
D4303 |
E4303 |
General purpose welding of carbon steel |
|
| S-4303.T |
D4303 |
E4303 |
All position high efficient welding |
|
| S-6010.D |
E6010 |
Cast steel repairs, pipes |
||
| S-6011.D |
E6011 |
D4311 |
E4311 |
Pipes, Thin steel sheets |
| S-6013.LF |
E6013 |
D4313 |
E4313 |
Low fume type electrodes for welding light structural steel |
| S-6013.V |
E6013 |
D4313 |
E4313 |
Welding steel sheets structure in ships for V-down welding |
| S-6027.LF |
E6027 |
D4327 |
E4327 |
Low fume type electrodes for highly efficient fillet welding, horizontal and flat fillet welding of ship |
| S-7014.F |
E7014 |
Sheet metal, high efficient welding |
||
| S-7024.F |
E7024 |
D4324 |
E4324 |
High efficient fillet welding |
| S-7016.O |
E7016 |
D4316 |
E4316 |
One side welding of pipe and general butt joints of carbon steel |
| S-7016.M |
E7016 |
D4316 |
E4316 |
Heavy duty structures, low alloy steel |
|
|
|
PRODUCT NAME |
STANDARD |
Specification |
||
|
AWS |
JIS |
KS |
||
| S-7016.H |
E7016 |
D5016 |
D5016 |
50f/ class high tensile steel |
| S-7016.LF |
E7016 |
D5016 |
D5016 |
Low fume type, 50f/ class high tensile steel |
| S-7016.G |
E7016 |
D5316 |
D5316 |
50f/ class high tensile steel of ships and vessel |
| S-7018.G |
E7018 |
D5016 |
D5016 |
50f/ class high tensile steel, rolling stock, bridges |
| S-7028.F |
E7028 |
D5026 |
D5026 |
Highly efficient welding of flat and horizontal fillet such as welding of high tensile steel |
| S-7048.V |
E7048 |
D5016 |
D5016 |
Vertical downward welding of 50f/ class high tensile steel |
| S-8016.G |
E8016-G |
D5316 |
D5316 |
60f/ class high tensile steel |
| S-8018.G |
E8018-G |
D5826 |
D5826 |
60f/ class high tensile steel |
| S-9016.G |
E9016-G |
D5816 |
D5816 |
60f/ class high tensile steel |
| S-10016.G |
E10016-G |
D7016 |
D7016 |
70f/ class high tensile steel, such as pressure vessels, penstock bridges |
| S-11016.G |
E11016-G |
D8016 |
D8016 |
80f/ class high tensile steel such as pressure vessel. penstock |
| S-9018.M |
E9018-M |
60f/ class high tensile steel used in presure vessels, bridges |
||
| S-11018.M |
E11018M |
80f/ class high tensile steel |
||
碳鋼和490N/mm2強度鋼用實芯焊絲
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| SM-70 |
ER70S-6 |
YGW12 |
YGW12 |
碳鋼和 50kg 級高強度鋼 |
| SM-70G |
ER70S-G |
YGW11 |
YGW11 |
碳鋼和 50kg 級高強度鋼用，高效率焊接 |
| SM-70S |
ER70S-3 |
YGW16 |
YGW16 |
碳鋼和 50kg 級高強度鋼 |
| SM-70GS |
ER70S-G |
YGW15 |
YGW15 |
碳鋼和 50kg 級高強度鋼用，高效率焊接 |
高強度鋼用實芯焊絲
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| SM-55H |
ER70S-6 |
YGW18 |
YGW12 |
碳鋼和 55kg 級高強度鋼用 |
| SM-80G | ER80S-G | YGW21 | YGW21 |
60kg 級高強度鋼用，高效率焊接 |
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| SM-308 |
ER308 |
Y308 |
Y308 |
18%Cr-8%Ni 不銹鋼 |
| SM-308L |
ER308L |
Y308L |
Y308L |
18%Cr-8%Ni 不銹鋼 |
| SM-309 |
ER309 |
Y309 |
Y309 |
22%Cr-12%Ni 不銹鋼 |
| SM-309L |
ER309L |
Y309L |
Y309L |
22%Cr-12%Ni 不銹鋼和碳鋼的異種金屬焊接 , |
| SM-310 |
ER310 |
Y310 |
Y310 |
25%Cr-20%Ni 不銹鋼 |
| SM-316 |
ER316 |
Y316 |
Y316 |
18%Cr-12%Ni-2%Mo 不銹鋼 |
| SM-316L |
ER316L |
Y316L |
Y316L |
18%Cr-12%Ni-2%Mo 不銹鋼 |
|
產品E |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| ST-308 |
ER308 |
Y308 |
Y308 |
18%Cr-8%Ni 不銹鋼 |
| ST-308L |
ER308L |
Y308L |
Y308L |
18%Cr-8%Ni 不銹鋼 |
| ST-309 |
ER309 |
Y309 |
Y309 |
22%Cr-12%Ni 不銹鋼 |
| ST-309L |
ER309L |
Y309L |
Y309L |
22%Cr-12%Ni 不銹鋼和碳素鋼的異種金屬焊接 , |
| ST-310 |
ER310 |
Y310 |
Y310 |
25%Cr-20%Ni 不銹鋼 |
| ST-316 |
ER316 |
Y316 |
Y316 |
18%Cr-12%Ni-2%Mo 不銹鋼 |
| ST-316L |
ER316L |
Y316L |
Y316L |
18%Cr-12%Ni-2%Mo 不銹鋼 |
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
|
F7A4-EL8 |
S502-H |
S502-H |
單層焊 , 單面焊 |
|
|
F7A(P)6-EM12K |
S502-H |
S502-H |
重要構造物的中厚鋼板單層、多層焊接 |
|
|
F7A(P)4-EH14 |
S502-H |
S502-H |
重要構造物的單層焊接、橫向焊接 |
|
|
F7A(P)6-EH14 |
S502-H |
S502-H |
重要構造物的單層、多層焊接 |
|
|
F7AZ-EH14 |
S502-H |
S502-H |
一般構造物的單層、多層焊接 |
|
|
|
|
|
單面焊接 |
|
|
F7A(P)0-EL8 |
S502-H |
S502-H |
高電流高效焊接 |
|
|
F7A(P)8-EH14 |
S502-H |
S502-H |
低溫用鋼的多層焊接 |
|
|
F7A(P)2-EH14 |
S502-H |
S502-H |
一般構造物的單層、多層焊接，橫向焊接 |
|
|
F8A(P)4-EA3-G |
S584-H |
S584-H |
60kg 級高強度鋼用 |
|
|
F7A0-EH14 |
S501-H |
S501-H |
一般構造物的薄板高速焊接 |
|
高強度碳鋼：
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| S-800P × M-12K(H-14) A-G(A-3) | A5.17 F7A2-EM12K F7A6-EH14, F7P6-EH14 A5.23 F8A4-EG-G F8A4-EA3-G, F8P2-EA3-G |
|
|
一般構造物的單層、多層焊，橫向焊接 |
底溫碳鋼：
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| S-787TB × H-14 | F7A(P)8-EH14 | S502-H | S502-H | 低溫鋼的單層、多層焊接 |
| Superflux 55ULT × H-14 |
A5.17 F7A(P)8-EH14
P)6-EH14 |
S502-H
2-H |
|
低溫鋼的多層焊接 |
|
產品 |
規格 |
特性 |
||
|
AWS |
JIS |
KS |
||
| Superflux 300S × YS308(L) |
|
FS S-B1/YS308(L) |
|
用于 18%Cr-8%Ni 鋼 焊接 |
| Superflux 300S × YS309(L) |
P)6-EH14 |
FS S-B1/YS309(L)
2-H |
|
用于 22%Cr-12%Ni 鋼焊接 |
| Superflux 300S × YS316(L) |
M12K |
FS S-B1/YS316(L) |
|
用于 18%Cr-12%Ni-2%Mo |
|
類型 |
產品 |
AWS Spec |
| Inconel 625 | SM-625 / ST625 | ER NiCrMo-3 |
| Inconel 82 | SM-82 / ST-82 | ER NiCr-3 |
| Inconel 60 | SM-60 / ST-60 | ER Ni-1 |
| Monel400 | SM-400 / ST-400 | ER NiCu-7 |
| Cupronikel 7030 | SM-7030 / ST-7030 | ER CuNi |
| Cupronikel 9010 | SM-9010 / ST-9010 | - |
| Hastalloy 276 | SM-276 / ST-276 | ER NiCrMo-4 |
|
|
類型 |
產品 |
AWS Spec |
| Sub | B2 | EB2 |
| Sub | B3 | EB3 |
| MIG,TIG | SM-80B2 / ST-80B2 | ER 80S-B2 |
| MIG,TIG | SM-90B3 / ST-90B3 | ER 90S-B3 |
| MIG | SM-100 | ER 100S-G |
| MIG | SM-110 | ER 110S-G |
| MIG | SM-120 | ER 120S-G |
|
產品 |
規格 |
特征 |
||
|
AWS |
JIS |
KS |
||
| SA-46, SA-43 |
A5.2 |
Z3201 |
D7005 |
用于碳鋼和低合金鋼的氧乙炔焊接 |
| SA-35 | ||||
| SA-46, SB-43 | ||||
|
SA-35, SB-32 |
||||
