產品牌號

Product Name

批號

Lot No

規格（mm）

Diameter

符合標準

Executed Standard

發證日期

Date of Issue

ERNiCr-3焊絲

587459

2.4mm

AWS :A5.14 ERNiCr-3

GB/TSNi6082

2016-06-04

產品化學成份（%）Chemical composition

成份

Element

C

Si

Mn

P

S

Fe

Ni

Cu

Ti

Cr

Nb

標準值

Standard Value

≤0.10

≤0.50

2.5-3.5

≤0.03

≤0.015

≤3.0

≥67.0

≤0.50

≤0.75

18.0-22.0

2.0-3.0

實測值

Test Value

0.05

0.35

3.2

0.009

0.008

2.0

70.0

0.35

0.65

21.0

2.5

熔敷金屬力學性能Mechanical properties of deposited metal

試驗項目Test item

Rm(MPa)

抗拉強度

0.2%耐力MPa

A(%)

延伸率

----

保證值Guarantee value

≥590

≥360

38%

----

一般結果General results

620

400

39

----

產品說明

Product description

ERNiCr-3用于熔化極氣體保護焊、鎢極惰性氣體保護焊和埋弧焊等方法焊接INCONEL 600\601\690合金，INCOLOY 800\800HT\330合金，還可用于鋼材的表面堆焊。用NI-ROD 99焊絲進行埋弧焊時應使用INCOFLUX 4埋弧焊劑。當用INCOFLUX 6埋弧焊劑進行埋弧焊時，焊道層數最多為三層。
用INCONEL82焊絲形成的焊縫金屬具有較高的強度和較好的耐蝕性，在高溫下具有較好的抗氧化能力和較高的蠕變破裂強度。

茲證明此產品符合上述標準之要求

This is to certify that the products conform to the above standards

AWS A…

EN…

SH Schwarz 3 T

5.5:

E8013-G

1599：

E Mo R 12

SH Schwarz 3 TR

5.5:

E8013-G

1599：

E Mo R 12

SH Kupfer 1 TR

5.5:

E8013-G

1599：

E CrMo 1 R 12

Phoenix Blau Mo

5.5:

E7011-A1

1599：

E Mo R 11

SH Schwarz 3 K

5.5:

E7015-G
(～A1)

1599：

E MoB 42 H5

SH Schwarz 3 KR

5.5:

E7015-G
(～A1)

1599：

E MoB 42 H5

SH Schwarz 3 MK

5.5:

E7018-G
(～A1)

1599：

E MoB 42 H5

SH Schwarz 3 K Ni

5.5:

E9018-G

499：

E 50 4 1 NiMo B 42 H5

Thyssen NiMo 100

5.5:

E10018-G
(～D2)

757：

E 62 4 Mn 1 NiMo B 42 H5

AWS 5.5:

EN1599：

Phoenix Chromo 1 K

E8018-B2

E CrMo 1 B 42 H5

Thyssen Chromo 1

E8018-B2

E CrMo 1 B 42 H5

SH Kupfer 1 K

E8018-B2

E CrMo 1 B 42 H5

SH Kupfer 1 KC

E8018-G(～B2)

EZ CrMo 1 B 42 H5

SH Kupfer 3 K

E9015-G

E CrMo 1 B 42 H5

SH Kupfer 3 KC

E9015-G

EZ CrMoV 1 B 42 H5

SH Chromo 2 KS

E9015-B3

E CrMo 2 B 42 H5

Thyssen Chromo 2 V

E9015-G

E CrMo 2 V B 42 H5

Thyssen Chromo 3 V

E9015-G

E CrMo 3 V B 42 H5

Thyssen Chromo 5

E8015-B6

E CrMo 5 B 42 H5

Thyssen Chromo 9 V

E9015-B9

E CrMo 9 1 B 42 H5

Thyssen Chromo T 91

E9015-B9

-

Thermanit MTS 4

-

E CrMoWV 12 B 42 H5

Thermanit MTS 616

E9015-G(～B9)

EZ CrMoWV 9 0.5 2 B 42 H5

Thermanit MTS 911

E9015-G(～B9)

E CrMo 9 1 1 B 42 H5

AWS A…

EN…

Phoenix 120 K

5.1:

E7018-1

499:

E 42 5 B 32 H5

SH Grün K 70

5.5:

E8018-G

499:

E 46 4 B 42 H5

SH Schwarz 3 K

5.5:

E7015-G
(～A1)

1599:

E MoB 42 H5

SH Schwarz 3 MK

5.5:

E7018-G
(～A1)

1599:

E MoB 42 H5

SH Schwarz 3 K Ni

5.5:

E9018-G

499:

E 50 4 1 NiMo B 42 H5

SH V 370

5.5:

E8018-C3

499:

E 46 6 1 Ni B 42 H5

SH V 1

5.5:

E8018-G
(～C3)

499:

E 50 6 Mn 2 Ni B 42 H5

SH Ni 2 K 70

5.5:

E8018-C1

499:

E 46 6 2 Ni B 42 H5

SH Ni 2 K 90

5.5:

E10018-M

757:

E 55 5 NiMo B 42 H5

SH Ni 2 K 100

5.5:

E11018-M

757:

E 69 5 Mn 2 NiCrMo B 42 H5

SH Ni 2 K 130

5.5:

E12018-G
(～M)

757:

E 89 4 Mn 2 Ni 1CrMo B 42 H5

AWS A…

EN…

Union I 1,2 Ni

GTAW

5.28:

ER80S-G

1668:

W3Ni1

Union I 5 Ni

GMAW

5.28:

ER80S-G

440:

G463CG3Ni1/G505MG3Ni1

Union I 2,5 Ni

GTAW

5.28:

ER80S-Ni2

1668:

W2Ni2

Union Ni 2,5

GMAW

5.28:

ER80S-Ni2

440:

G506MG2Ni2

AWS A5.28:

G EN 12534:

Union MoNi

GMAW

ER90S-G

G Mn3Ni1Mo

Union NiMoCr

GMAW

ER100S-G(~1)

G Mn4Ni1,5CrMo

Union X 85

GMAW

ER110S-G

G Mn4Ni1,5CrMo

Union X 90

GMAW

ER120S-G

G Mn4Ni2CrMo

Union X 96

GMAW

ER120S-G

G Mn4Ni2,5CrMo

AWS A5.28:

EN…

Union I Mo

GTAW

ER80S-G

1668：
12070：

W2Mo
W MoSi

Union I Mo*

GMAW

ER80S-G

440：
12070：

G2Mo
G MoSi

Thyssen MV Mo*

MCAW

ER80C-G H4

758：
12071：

T 46 2 Mo M M 2 H5
T Mo MM 2 H5

AWS A…

EN…

Union I CrMo

GTAW

5.28:

ER80S-G

12070:

W CrMo 1 Si

Union I CrMo*

GMAW

5.28:

ER80S-G

12070:

G CrMo 1 Si

Thyssen MV CrMo

MCAW

5.28:

E80C-B2 H4

12071:

T CrMo1 MM2 H5

Union I CrMo 910

GTAW

5.28:

ER90S-G

12070:

W CrMo 2 Si

Union I CrMo 910*

GMAW

5.28:

ER90S-G

12070:

G CrMo 2 Si

Union I Cr 2 WV

GTAW

5.28:

ER90S-G

12070:

W ZCrWV2

Union I Cr 2 WV*

GMAW

5.28:

ER90S-G

12070:

G ZCrWV2

Union I CrMoVTi B

GTAW

5.28:

ER90S-G

12070:

W ZCrMoV2

Union I CrMoVTi B*

GMAW

5.28:

ER90S-G

12070:

G ZCrMoV2

Union I CrMo 5

GTAW

5.28:

ER80S-B6

12070:

W CrMo 5 Si

Union I CrMo 5*

GMAW

5.28:

ER80S-B6

12070:

G CrMo 5 Si

Thermanit MTS 3

GTAW

5.28:

ER90S-B9

12070:

W CrMo 9 1

Thermanit MTS 3*

GMAW

5.28:

ER90S-B9

12070:

G CrMo 9 1

Thermanit MTS 3 FD*

MCAW

5.28:

E90C-B9 H4

12071:

T ZM M 2 H5

Thermanit MTS 4 Si

GTAW

-

-

12070:

W CrMoWV 12 Si

Thermanit MTS 4 Si*

GMAW

5.9:

≈ER505

12070:

G CrMoWV 12 Si

Thermanit MTS 616

GTAW

5.28:

ER90S-G

12070:

W Z CrMoWVNb 9 0.5 1.5

Thermanit MTS 616*

GMAW

5.28:

ER90S-G

12070:

G Z CrMoWVNb 9 0.5 1.5

Thermanit MTS 911

GTAW

5.28:

ER90S-G

12070:

W Z CrMoWVNb 9 1 1

Thermanit MTS 911*

GMAW

5.28:

ER90S-G

12070:

G Z CrMoWVNb 9 1 1

AWS A…

EN

Union Patinax**

GMAW

5.18:

ER70S-G

440:

G423CG0/G464MG0

*保護氣體為M21(氬氣+15至25%CO2)
