| 分類: | E7018-G, SFA/AWS A5.5, E 46 6 Mn1Ni B 32 H5, EN ISO 2560-A |
| 認證: | 3Y H5, ABS, 3Y H5, BV, EN 13479, CE, 3Y H5, DNV, 6Y H5, GL, 5Y42 H5, LR, UNA 272581, Seproz |
Approvals are based on factory location. Please contact ESAB for more information.
| Coating Type: | Basic |
| Diffusible Hydrogen: | < 5.0 ml/100g |
| Welding Current: | AC, DC+- |
| Impact Value | Testing Temperature |
| ISO As welded | |
| 110 J | -40 °C |
| 75 J | -60 °C |
| Elongation | Tensile Strength | Yield Strength |
| ISO As welded | ||
| 28 % | 630 MPa | 550 MPa |
| AWS As welded | ||
| - | - | - |
| Fusion time per electrode at 90% I max | kg weld metal/kg electrodes | Number of electrodes/kg weld metal | 安培 | 熔敷率 | 電壓 V | 直徑 |
| 59 hr | 0.65 kg | 87 | 55-85 A | 0.7 kg/h | 24 V | 2.5 x 350 mm |
| 63 hr | 0.63 kg | 55 | 100-125 A | 1.05 kg/h | 21 V | 3.0 x 350 mm |
| 60 hr | 0.57 kg | 54 | 80-140 A | 1.12 kg/h | 23.8 V | 3.2 x 350 mm |
| 63 hr | 0.61 kg | 41 | 125-175 A | 1.4 kg/h | 21.6 V | 3.5 x 350 mm |
| 78 hr | 0.63 kg | 31 | 120-180 A | 1.51 kg/h | 22 V | 4.0 x 350 mm |
| 109 hr | 0.608 kg | 24 | 120-170 A | 1.4 kg/h | 22.2 V | 4.0 x 450 mm |
| 106 hr | 0.62 kg | 15 | 180-270 A | 2.22 kg/h | 24.3 V |
5.0 x 450 mm |
