產品全檢。內套和外套可以互換使用，按您要求來做包裝，如有需要，歡迎隨時詢價！
| Bearing No. | Dimensions (mm) | Load Ratings (KN) | Mass | |||||||
| d | D | B | C | T |
r min |
r1 min |
C | Co | kg | |
| H715345/H715311 | 71.438 | 136.525 | 46.038 | 36.512 | 46.038 | 3.50 | 3.3 | 232.00 | 368.00 | 3.053 |
| HH221449/HH221410 | 101.600 | 190.500 | 57.531 | 46.038 | 57.150 | 8.00 | 3.3 | 445.00 | 610.00 | 6.890 |
| HM88649/HM88610 | 34.925 | 72.233 | 25.400 | 19.842 | 25.400 | 2.30 | 2.3 | 58.00 | 69.00 | 0.491 |
| HM89449/HM89410 | 36.512 | 76.200 | 28.575 | 23.020 | 29.370 | 3.50 | 3.3 | 106.10 | 79.20 | 0.620 |
| HM212047/HM212011 | 63.500 | 122.238 | 38.354 | 29.718 | 38.100 | 7.00 | 3.3 | 187.00 | 244.00 | 1.340 |
| HM212049/HM212011 | 66.675 | 122.238 | 38.354 | 29.718 | 38.100 | 3.50 | 3.3 | 187.00 | 244.00 | 1.850 |
| HM518445/HM518410 | 88.900 | 152.400 | 39.688 | 30.162 | 39.688 | 6.40 | 3.3 | 253.00 | 365.00 | 2.110 |
| HM218248/HM218210 | 89.974 | 146.975 | 40.000 | 40.000 | 32.500 | 7.00 | 3.5 | 227.00 | 340.00 | 2.550 |
| HM220149/HM220110 | 99.975 | 156.975 | 42.000 | 34.000 | 42.000 | 8.00 | 3.5 | 298.00 | 410.00 | 2.860 |
| J16154/J16285 | 39.000 | 72.014 | 20.638 | 16.637 | 21.400 | 3.10 | 1.1 | 74.42 | 56.01 | 0.354 |
| JL69349/JL69310 | 38.000 | 63.000 | 17.000 | 13.500 | 17.000 | 3.50 | 1.3 | 39.00 | 53.00 | 0.199 |
| JL819349/JL819310 | 95.000 | 135.000 | 20.000 | 14.000 | 20.000 | 4.50 | 2.0 | 133.00 | 69.20 | 0.830 |
| JLM104948/JLM104910 | 50.000 | 82.000 | 21.501 | 17.000 | 21.501 | 3.00 | 0.5 | 70.00 | 94.00 | 0.419 |
| JLM813049/JLM813010 | 70.000 | 110.000 | 25.000 | 20.500 | 26.000 | 1.00 | 2.5 | 102.00 | 156.00 | 0.868 |
| JM205149A/JM205110 | 50.000 | 90.000 | 28.000 | 23.000 | 28.000 | 3.00 | 2.5 | 105.00 | 138.00 | 0.720 |
| JM207049A/JM207010 | 55.000 | 95.000 | 29.000 | 23.500 | 29.000 | 6.00 | 2.5 | 110.00 | 150.00 | 0.256 |
| JM515649/10 | 80.000 | 130.000 | 34.000 | 28.500 | 35.000 | 3.20 | 2.5 | 252.00 | 151.00 | 1.749 |
| JM716649/JM716610 | 85.000 | 130.000 | 29.000 | 24.000 | 30.000 | 3.00 | 2.5 | 135.00 | 214.00 | 1.348 |
| JM720249/JM720210 | 100.000 | 155.000 | 35.000 | 28.000 | 36.000 | 3.00 | 2.5 | 235.00 | 370.00 | 2.380 |
| JM822049/JM822010 | 110.000 | 165.000 | 35.000 | 26.500 | 35.000 | 3.00 | 2.5 | 191.00 | 315.00 | 2.443 |
| JP12049/12010 | 120.000 | 170.000 | 25.000 | 19.500 | 27.000 | 1.742 | ||||
| K-HM518445/K-HM518410 | 88.900 | 152.400 | 39.688 | 30.162 | 39.688 | 6.40 | 3.3 | 361.20 | 242.40 | 2.850 |
| L44643/10 | 25.400 | 50.292 | 14.732 | 10.668 | 14.224 | 1.30 | 1.3 | 32.20 | 27.80 | 0.126 |
| L44649/10 | 26.988 | 50.292 | 14.732 | 10.668 | 14.224 | 3.50 | 1.3 | 32.20 | 27.80 | 0.119 |
| L45449/10 | 29.000 | 50.292 | 14.732 | 10.668 | 14.224 | 3.50 | 1.3 | 34.00 | 24.80 | 0.113 |
| L68149/L68111 | 34.988 | 59.974 | 16.764 | 11.938 | 15.875 | 3.90 | 1.3 | 47.50 | 35.30 | 0.180 |
| LM11749/LM11710 | 17.462 | 39.878 | 14.605 | 10.668 | 13.843 | 1.30 | 1.3 | 22.60 | 22.50 | 0.080 |
| LM11949/LM11910 | 19.050 | 45.237 | 16.637 | 12.065 | 15.494 | 1.30 | 1.3 | 30.00 | 29.00 | 0.120 |
| LM67048/LM67010 | 31.750 | 59.131 | 16.764 | 11.811 | 15.875 | 5.00 | 1.3 | 32.00 | 36.00 | 0.175 |
| LM48548/LM48510 | 34.925 | 65.088 | 18.288 | 13.970 | 18.034 | 4.90 | 1.3 | 47.00 | 56.00 | 0.246 |
| LM48549X/10 | 34.925 | 65.088 | 18.288 | 13.970 | 18.034 | 2.36 | 1.3 | 57.50 | 46.00 | 0.257 |
| LM29749/LM29710 | 38.100 | 65.088 | 18.288 | 13.970 | 18.034 | 2.30 | 1.3 | 44.00 | 57.00 | 0.238 |
| LM29749/LM29711 | 38.100 | 65.088 | 18.288 | 15.748 | 19.812 | 2.30 | 1.3 | 44.00 | 57.00 | 0.251 |
| LM300849/LM300811 | 40.988 | 67.975 | 18.000 | 13.500 | 17.500 | 3.50 | 1.5 | 62.10 | 43.50 | 0.243 |
| LM501349/LM501310 | 41.275 | 73.431 | 19.812 | 14.732 | 19.558 | 3.50 | 0.8 | 56.00 | 70.00 | 0.335 |
| LM501349/LM501314 | 41.275 | 73.431 | 19.812 | 16.604 | 21.430 | 3.50 | 0.8 | 56.00 | 70.00 | 0.323 |
| LM102949/10 | 45.242 | 73.431 | 19.812 | 15.748 | 19.558 | 3.50 | 0.8 | 79.00 | 51.40 | 0.308 |
| LM603049/LM603011 | 45.242 | 77.788 | 19.842 | 15.080 | 19.842 | 3.50 | 0.8 | 72.30 | 56.50 | 0.365 |
| LM603049/LM603012 | 45.242 | 77.788 | 19.842 | 16.667 | 21.430 | 3.50 | 0.8 | 58.00 | 74.00 | 0.377 |
| LM603049/LM603014 | 45.242 | 79.974 | 19.842 | 15.080 | 19.842 | 0.398 | ||||
| LM603049A/LM603014 | 45.242 | 79.974 | 19.842 | 15.080 | 19.842 | 0.80 | 1.0 | 73.80 | 57.60 | 0.398 |
| LM104949/LM104910 | 50.800 | 82.550 | 22.225 | 16.510 | 21.590 | 3.50 | 1.3 | 70.00 | 94.00 | 0.419 |
| M12649/10 | 21.430 | 50.005 | 18.288 | 13.970 | 17.526 | 0.172 | ||||
| M86647/M86610 | 28.575 | 64.292 | 21.433 | 16.670 | 21.433 | 1.50 | 1.5 | 64.00 | 53.00 | 0.350 |
| M88043/M88010 | 30.162 | 68.262 | 22.225 | 17.462 | 22.225 | 2.30 | 1.5 | 71.40 | 56.20 | 0.407 |
| M88649/M88610 | 30.162 | 64.292 | 21.433 | 16.670 | 21.433 | 1.50 | 1.5 | 47.00 | 56.00 | 0.338 |
| M5R2-124 | 39.688 | 89.980 | 22.128 | 20.856 | 25.580 | 5.00 | 2.5 | 59.00 | 124.00 | 0.747 |
| M802048/M802011 | 41.275 | 82.550 | 25.645 | 20.193 | 26.543 | 3.50 | 3.3 | 81.00 | 104.00 | 0.623 |
| TR081004 | 40.000 | 95.000 | 36.000 | 28.000 | 36.250 | 2.50 | 20 | 139.00 | 167.00 | 1.000 |
